22.3 mm x 14.9 mm CMOS

Approx. 24.10 megapixels

Approx. 25.80 megapixels

3:2

Built-in/Fixed

EOS integrated cleaning system

Primary Colour

DIGIC 8

EF and EF-S mount

Approx. 1.6x the focal length of the lens

Optical Image Stabilizer on compatible lenses

Via optical viewfinder: TTL secondary image-forming phase-difference detection system with AF-dedicated sensor.
Via LiveView on LCD screen: Dual Pixel CMOS AF System. Phase detection pixels built onto imaging sensor¹

Via optical viewfinder: 9-point Center AF point is AF cross-type supporting f/5.6. Center AF point is vertical line-sensitive supporting f/2.8. Other AF points are vertical line-sensitive or horizontal line-sensitive AF supporting f/5.6. ²
Via LiveView on LCD screen: Maximum 143 AF points via camera automatic selection ³Freely position 1 AF point/1 AF Zone max 3,975 points via manual selection ¹

Via optical viewfinder: EV -0.5 – 18 (center AF point)⁴ EV 0.5 – 18 (other AF points) ⁴
Via LiveView on LCD screen: EV -4 – 18 (f/1.2 at 23 °C & ISO 100) with One-Shot AF

AI Focus, One Shot, AI Servo (AI Servo II algorithm)

Via optical viewfinder:

Automatic selection: 9 point AF
Manual selection: Single point AF

Indicated by a transmissive LCD in viewfinder and Quick Control screen

Locked when shutter button is pressed half way in One-Shot AF mode or AF-ON Button is pressed.

Emitted by optional dedicated Speedlite

Selected on lens

Via optical viewfinder:

63-zone dual-layer metering sensor with Evaluative, partial, spot (centre only) and centre-weighted average available

Via LiveView on LCD screen:

(1) Evaluative metering (384 zones)
(2) Partial metering (approx. 5.5 % of LCD screen)
(3) Spot metering (approx. 3.7 % of LCD screen)
(4) Center-weighted average metering

Via optical viewfinder: EV 1 – 20 (at 23 °C with 50 mm f/1.4 lens ISO 100) Via LiveView on LCD screen: EV -2 – 20 (at 23 °C, ISO 100, evaluative metering)

Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE Lock Button in creative zone modes.

+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).

3 shots +/-2 EV 1/3 or 1/2 stop increments

Auto (100-25600), 100-25600 (in whole stop increments)
ISO can be expanded to H: 51200
During Movie shooting: Auto (100-12800), 100-12800 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 25600. 4K Movie Max. 6400

Electronically-controlled focal-plane shutter

30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)

Automatic white balance with the imaging sensor

AWB (Ambience priority, White priority), Daylight, Shade, Cloudy, Tungsten light, White, Fluorescent light, Flash, Custom, Colour Temperature Setting. White balance compensation: 1. Blue/Amber bias +/-9 levels. 2. Magenta/ Green bias +/-9 levels

Yes, 1 setting can be registered

+/-3 levels in single level increments
3 bracketed images per shutter release.
Selectable Blue/Amber bias or Magenta/Green bias.

Pentamirror

Approx. 95 %

Approx. 0.87x ⁵

-3 to +1 m-1 (dioptre)

Fixed (Translucent LCD screen for information overlay)

Quick-return half mirror (Transmission: reflection ratio of 40:60, no mirror cut-off with EF 600 mm f/4 IS USM or shorter)

AF information: AF points, focus confirmation, AF area selection mode. Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, spot metering circle, exposure warning, AEB. Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation.
Image information: Card information, maximum burst (1 digit display), Highlight tone priority (D+). Composition information: Grid, Aspect Ratio. Other information: Warning icon.

Yes, with Depth of Field preview assigned to a button via Custom Function.

On strap

Vari-angle touchscreen 7.7 cm (3.0″) 3:2 Clear View II TFT, approx. 1040 K sRGB dots

Approx. 100%

Approx. 170°

Adjustable to one of seven levels

(1) Quick Control Screen
(2) Camera settings

9.8

up to 18 mm focal length (35 mm equivalent: approx. 29mm)

Approx. 3 seconds

Auto, Manual flash

X-Contact is not equipped. 1/200 sec

+/- 2 EV in 1/2 or 1/3 increments

Yes, with compatible External Flash

Yes

Yes

Yes/ No

E-TTL II with EX series Speedlites, wireless optical multi-flash support

via camera menu screen

Scene Intelligent Auto (Stills and Movie), Creative Auto, SCN(Portrait, Landscape, Close-up, Sports, Group Photo, Night Portrait, Smooth Skin, Group Photo, Handheld Night Scene, HDR Backlight Control, Food, Kids, Candlelight), Creative filters, Program AE, Shutter priority AE, Aperture priority AE, Manual (Stills and Movie)

Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)

sRGB and Adobe RGB

Highlight Tone Priority (3 settings) Auto Lighting Optimizer (4 settings) Long exposure noise reduction High ISO speed noise reduction (4 settings) Multi Shot Noise Reduction Auto Correction of Lens Peripheral illumination, Chromatic aberration correction, Distortion correction, Diffraction correction Digital Lens Optimizer Creative filters (Grainy B/W, Soft focus, Fish-eye effect, Water painting effect, Toy camera effect, Miniature effect, HDR art standard, HDR art vivid, HDR art bold, HDR art embossed)

Multi-exposure Resize, Crop (JPEG only)

Single, Continuous L, Continuous H, Self timer (2s+remote, 10s +remote)

Max. Approx. 5 fps.

Approx. 100% (horizontally and vertically)

29.97 fps

Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Dual Pixel CMOS AF (Face detection and Tracking AF, FlexiZone-Multi, FlexiZone-Single)
One-shot AF and Servo AF selectable for Stills and Movie

Real-time evaluative metering with image sensor.
Evaluative metering, partial metering, spot metering, center-weighted average metering.

Grid overlay (x3), Histogram,

JPEG: Fine, Normal (Exif 2.31 [Exif Print] compliant) / Design rule for Camera File system (2.0)

RAW: 14bit, Canon original RAW 3rd edition Digital Print Order Format [DPOF] Version 1.1 compliant

RAW, RAW + JPEG (any combination) possible.

JPEG 3:2: (L) 6000 x 4000, (M) 3984 x 2656, (S1) 2976 x 1984, (S2) 2400×1600,
JPEG 4:3: (L) 5328×4000, (M) 3552×2664, (S1) 2656×1992, (S2) 2112×1600,
JPEG 16:9: (L) 6000×3368, (M) 3984×2240, (S1) 2976×1680, (S2) 2400×1344,
JPEG 1:1: (L) 4000×4000, (M) 2656×2656, (S1) 1984×1984, (S2) 1600×1600,
RAW: (RAW) 6000×4000

MP4 (Video: H.264 inter frame, Sound: Linear PCM / AAC, recording level can be manually adjusted by user) MOV (Video: H.264 All-I Full HD, no sound) – time-lapse movie only

3840 x 2160 (23.98, 25 fps) inter-frame
1920 x 1080 (59.94, 50 fps) inter-frame
1920 x 1080 (29.97, 25 fps) inter-frame
1920 x 1080 (29.97, 25) lite inter-frame
1280 x 720 (59.94, 50 fps) inter-frame

Max duration 29min 59sec

New folders can be manually created and selected

(1) Consecutive numbering
(2) Auto reset
(3) Manual reset

11 Custom Functions

User copyright information (can be set in camera)
Image rating (0-5 stars)

Yes

1.5x – 10x

(1) Single image with information (2 levels)
(2) Single image
(3) 4-image index
(4) 9-image index
(5) 36-image index
(6) 100-image index
(7) Jump Display

Choose images with Image Search
Playback time: 1/2/3/5/10/20 seconds
Repeat: On/Off
Background music: On/Off
Transition effect: Off, Slide in 1, Slide in 2, Fade 1, Fade 2, Fade 3

Brightness: Yes
RGB: Yes

Yes

Erase: Select image, select range, all images in folder, all images on a card, all found images (during image search)
Protection: Single image, select range, all images in folder, all images on a card, all found images (during image search)

Menu interface adjustable by the user between standard and guided

(1) Shooting menu
(2) Playback menu
(3) Setup menu
(4) Display Options menu
(5) My Menu

29 Languages
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Japanese, Vietnamese, Hindi, Malay, Indonesian

Update possible by the user.

Chassis: Aluminium alloy and polycarbonate resin with glass fibre
Exterior: Polycarbonate resin with glass fibre and special conductive fibre

Hi-Speed USB

Wi-Fi (2.4GHz) Channels: IEEE802.11b, IEEE802.11g, IEEE802.11n

Camera Access Point: WPA2-PSK with AES encryption or open
Infrastructure: Shared key, with WEP encryption, WPA-PSK/WPA2-PSK with TKIP/AES encryption or open

BLE (Bluetooth Low Energy Technology)

Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (HDMI-CEC compatible), External microphone (3.5 mm Stereo mini jack)

Canon Compact Photo Printers and PIXMA Printers supporting PictBridge

Yes

SD, SDHC, SDXC (UHS Speed Class 1 compatible)

See individual software

Digital Photo Professional 4 (RAW Image Processing)

EOS Utility
EOS Lens Registration Tool
EOS Web Service Registration Tool
EOS Sample Music
Picture Style Editor

Camera Connect app available on iOS and Android devices

1 x Rechargeable Li-ion Battery LP-E17

Viewfinder: Approx. 1070 (at 23°C, AE 50%, FE 50%) (5)
Viewfinder: Approx. 1020 (at 0°C, AE 50%, FE 50%)
LiveView: Approx. 320 (at 23°C, AE 50%, FE 50%)
LiveView: Approx. 300 (at 0°C, AE 50%, FE 50%)

4 levels

Power turns off after 10/30 (10 sec viewfinder/30 sec live view, functions, image playback etc) sec, 30 sec, 1, 2, 4, 8, or 15 mins.

Battery charger LC-E17E

Eyecup Ef
Rubber Frame Ef
E-series Dioptric Adjustment Lenses
Eyepiece Extender EP-EX15II
Magnifier MG-Ef
Angle Finder C

All EF and EF-S lenses

Canon Speedlites (90EX, 220EX, 270EX, 270EX II, 320EX, 420EX, 430EX, 430EX II, 430EX III-RT, 550EX, 580EX, 580EX II, 600EX, 600EX-RT, Macro-Ring-Lite, MR-14EX, Macro Twin Lite MT-24EX, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT) ⁴

Remote Switch RS-60E3, Remote Controller BR-E1, Timer Remote Controller TC-80N3 via Remote Controller Adapter RA-E3

Hand Strap E2, GPS Receiver GP-E2, Directional Stereo Microphone DM-E1, Protecting Cloth PC-E1, PC-E2, HDMI Cable HTC-100, Canon Interface Cable IFC-600PCU
